Technical Index:
Laser source : 300W Raycus Fiber Laser
Working size: 1300mm*2500mm
Cutting thickness: 0.1-8mm (Depending on the material)
Position accuracy: 0.03mm
Repeat Precision: 0.02mm
X Axis Route: 3050mm
Y Axis Route: 1525mm
Z Axis Route: 120mm
Maximum cutting speed: 20m/min.
Operating temperature: 0℃-40℃
Workbench maximum load: 100kg
Drive type of X, Y axis: Imported servo drive( Panasonic, Japan)
Servo motor- Japan Panasonic servo motor
Control system: au3tech Sc1000
Software support formats: AI, BMP, PLT, DXF, DST etc
Ball screw transmission: Taiwan TBI ball screw
Guide Rail: Taiwan: HIVIN Guide
Moving mode: Imported TBI rolling ball screw
Auxiliary gas: N2 ,O2
Machine size(L*W*H): 3800*1850*1300mm
Net weight: 2000kg
Application:
Cutting on plate or tube in metal, mainly for cutting on SS, carton steel, manganese steel, galvanized plate, alloy plate, rare metal.
Widely used in kitchen appliance, electric control box, high-resolute device, mechanical equipment, electrical equipment, lighting,
poster, auto parts, display equipment, hardware and metal processing.
