Features:
1. High degree of automation, and the use of printing "one-button" operation, effectively improve work efficiency.
2. The structure design is reasonable, the height of the whole machine is low, the operation is convenient, and the amount of paper loaded at one time is large.
3. The electrical appliances are controlled by microcomputer, and the man-machine interface is touch screen. Paper feeding and dialing are controlled by pneumatic components, which fully guarantees the stable and reliable operation of the machine.
4. Double sheets use ultrasonic for accurate detection, and also have detections such as idling, paper jams, and paper jams.
5. Equipped with automatic oil and ink supply device, vertical and horizontal rice noodles can be set at will according to need.
6. The feeding angle of each paper feeding unit is small, which can effectively ensure the smooth conveyance of different papers.
7. Double-fed code sorting printing machine can realize edge-joint printing.
8. Optional satellite dual color head and dual coding system.
9. The pressure between the printing plate cylinder, the impression cylinder and the rubber cylinder is pneumatically combined. Compared with the traditional electromagnet lever structure, it solves the situation of easy damage in the lever mode. And the pressure is stable, the online store is clear, and the reduction is good.
技术参数:
机型Type:DSS-ZJ47AS2NP-4PY
最大用纸尺寸Max. paper size:470×365mm
最大印刷面积Max. printing area:450×345mm
最小用纸尺寸Min. paper size:210×210mm
纸张类型 Paper weight:28-157g/m2
墨辊数量No. of ink rollers:主机系统10根(靠版墨辊2根) NP 系统(一组)6根(靠版2根)
Main system :10pcs ink rollers (2pcs form ink rollers)
NP system: 6pcs ink rollers(2pcs form ink rollers)(one set)
水辊数量No. of dampening rollers:4根(靠版水辊1根) 4pcs(1pc form dampening roller)
套准机构Registering mechanism:轮滚式侧拉规 Roller type side lay
印刷速度Printing speed:2000-6000张/小时 2000-6000 sheets/hour
号码最小间距Min. space between codes:竖码:纵向71mm 横向 48mm Vertical Number: vertical: 71mm,horizontal:48mm
横码:纵向 47mm 横向 60mm Horizontal Number: vertical:47mm,horizontal:60mm
电机功率 Motor power:主电机 2.2KW/220V 气泵电机:0.55KW/220V×4台
Main motor:2.2KW/220V Pump motor:0.55KW/220V ×4SETS
机器尺寸 Machine size:2900×935×1680mm
重量 Weight:1860KG
