Product Name : |
1201CHL single head 12 needles dahao computer embroidery machine |
Head:1 head
Needle:12 needles
Weight:350kg
Embroidery area:550*1200mm
Speed:1200RPM
Machine size:1460*1120*1600mm
Control System:10" LCD Daohao control system
Computer:Newest Dahao D19
Worktable Size:1760*1300MM
Operating languages:12 different languages
package size: 1580*1150*1600mm(standard wooden box package )
Function: Flat embroidery / cap embroidery / 3D embroidery /T-shirt embroidery /Sequin Embroidery Machine /Chain-stitch Chenille embroidery machine
BECS D19 series embroidery machine computer control system - facing high speed towel chain embroidery processing market
Color-changing times up to 1000 times
An increased memory capacity of 100 million stitches
Support maximum stitch number for single pattern of 2 million stitches;
Support intelligent encryption mode for payment installment;
Optimized looping embroidery control algorithm and high-speed looping drive technology to realize super high-speed rotation at 1200rpm
I. Main features of the Chenille embroidery machine
1. suitable for flat bed, cap and finished garments embroidery
2. Embroidery area: 600*1200 mm, or 23.6" x 47.2"
3. Automatic thread trimmer
4. Maximum speed 1200 RPM
5. 270° Wide cap frame unit
6. 10 inch touch screen display showing real time stitching
7. USB port ready
8. Auto color change
9. Thread break detection
10. Pre-Sew Design Trace capable
11. Memory size: 2, 000, 000 stitches
12. Electricity: 110V/60Hz or 220V/50Hz available
13. Start, Stop, and Emergency Stop
II. Dahao Full coler control panel
1.10" High Definition color LCD display showing
Real time stitching
2. Function keys including Menu, Speed up and slow
Down (also Page Up and Page Down), Help, USB-
Input, Parameter Settings, Clear, ESC, Enter, etc.
3. Numeric keys for selection of needles
4. Frame-moving keys
5. Manual Trimming
6. Manual Color Change
7. Embroidery Status
8. Embroidery Method
9. DOT Key to return to 100 degrees
10. Mutli languages available
