MODEL
|
UD-3212LDU
|
Printhead
|
DX5
|
Number
of printhead
|
2
Heads
|
Maximum
Print Width
|
3,200mm
|
Maximum
Media Width
|
3,300mm
|
Print
Speed (m2/h)
|
Print
mode
|
Standard
output(m2/h)
|
D
|
3
PASS 22
|
S
|
4
PASS 16
|
Q
|
6
PASS 11
|
HQ
|
8
PASS 8
|
BL
|
12
PASS 11
|
Ink
|
Type:
|
UV
Ink
|
Color
:
|
4
Color (C,M,Y,K)
|
Capacity:
|
1L per Main Tank of Each Color
|
Ink
Supply System
|
Auto
Ink Supply System
|
Media
Type
|
Ceilling
film, Vinyl, PS Board, KT Board, PVC Foam Board, Window Flim, Polyester,
Flex, Back-lit Film, etc.
|
Auto
Media Feeding System
|
Equipped
(Max. Media Weight40kg)
|
Auto
Cleaning System
|
Anti-clogged
Flash Function & Capping System
|
Pre-heating
& Drying System
|
Equipped
|
Clamp
|
Equipped
|
Print
Interface
|
USB
2.0
|
Printhead
Height
|
2
to10 mmfrom Media
|
RIP
Software
|
Ultraprint,
Maintop, Photoprint, Wasatch, Onyx
|
Input
Power
|
AC
220V, 50Hz/60Hz
|
Operating
Environment
|
Humidity:
20-80% (Recommend 40-60%)
|
Temperature:
15-35°C(Recommend
20-32)
|
Machine
Dimension / N.W
|
L4,700
x W905 x H1,260mm/304KG
|
Package
Dimension / G.W
|
L4,790
x W1,100 x H940mm/547KG
|
