Model
|
UD-161LC
|
UD-1612LC
|
Full aluminum platform / Bearing rail,
stable and long durability
|
Print head
|
DX5
|
Number of print head
|
1 Head
|
2 Head
|
Maximum print width
|
1,600mm
|
Print Speed (m2/h)
|
Print mode
|
Standard output(m2/h)
|
RD
|
2 PASS 29
|
2 PASS 53
|
D
|
3 PASS 19
|
3 PASS 35
|
S
|
4 PASS 14
|
4 PASS 26
|
Q
|
6 PASS 9
|
6 PASS 17
|
HQ
|
8 PASS 7
|
8 PASS 13
|
BL
|
12 PASS 4
|
12 PASS 8
|
Ink
|
Type:
|
Water based / Eco Solvent Ink
|
Color :
|
4 Color (C,M,Y,K)
|
Capacity:
|
1L per Main Tank of Each Color
|
Ink Supply System
|
Auto Ink Supply System
|
Media Width
|
Maximum1,680mm
|
Media Type
|
Vinyl, Polyester, Flex, Back-lit Film, PS
Board, KT Board, PVC Board, etc.
|
Auto Media Feeding System
|
Equipped (Max. Media Weight25kg)
|
Auto Cleaning System
|
Anti-clogged Flash Function & Capping
System
|
Pre-heating & Drying System
|
Equipped
|
Clamp
|
Equipped
|
Print Interface
|
USB 2.0
|
Print head Height
|
2 to6 mm from Media
|
RIP Software
|
Ultraprint, Maintop, Photoprint, Wasatch,
Ergosoft
|
Input Power
|
AC 220V, 50Hz/60Hz
|
Machine Dimension / N.W
|
L2,820 x W990 x H1,260mm / 200KG
|
Package Dimension / G.W
|
L2,860 x W1,050 x H685mm / 377KG
|
Shipping info.:
Measurement for 1 set:2.057CBM
|
