Model
|
19P2-R
|
Printhead
|
Two 5113 Drop-On-Demand Micro-Piezo Print Heads
|
Number of Nozzle
|
6400 Nozzles (2 Heads)
|
Color
|
4 Colors:Y, M, C, K
|
Resolution
|
1440dpi (Max)/1440dpi
|
Size of Ink Droplet
|
1.5-21 Pl
|
Max. Printing Width
|
1850mm(72'')
|
Printing Speed
|
2 Pass 65 Sqm/H
|
4 Pass 38 Sqm/H
|
6 Pass 25 Sqm/H
|
8 Pass 14 Sqm/H
|
Media Feedup
|
yes
|
Media Takeup
|
yes
|
Media Max Weight
|
100 KG
|
Media Type
|
Flex,Banner,Knife Coated Substrate,Double Side Printing Banner PVC,Advertising Cloth,Adhesive Vinyl,One Way Vision, Mesh,Reflective Banner,Reflective Vinyl,Eco Solvent Media
|
Media Dryer
|
Fan Drying System, Infrared Heating
|
Ink Tank Volume
|
1800ml*4=7200ml
|
Cleaning System
|
Auto Cleanning System With Anti Clogged Flash Spray & Moisturizing Function
|
Power
|
AC220-240V 50-60HZ Or AC110-120V 50-60HZ
|
Control System
|
Titanjet PrintSystem
|
RIP System
|
Maintop or PhotoPrint
|
Operation System
|
MS Windows 7
|
Printing Environment
|
Temperature 18-28 Degrees, Humidity 50-75 Rh
|
Printer Dimensions
|
3.0 M(L)*0.9 M(W)*1.43 M(H)
|
Packing Dimensions
|
3.16 M(L)*0.81 M(W)*0.81 M(H)
|
Net Weight
|
390KG
|
Gross Weight
|
420KG
|
